Désignation des produits
Pallet Rack,Storage Warehouse,Warehouse Racking System
Pallet Rack is a most useful and effective storage racking system providing direct access to all pallets.
It provides high capacity storage which is easily installed and adjusted with low equipment and capital costs.

RACK FEATURES:

1. Heights from 2500 mm to 11800 mm

2. Frame depth from 800 mm to 1200 mm

3. Rack capacity from 800 to 4000 Kg per level

4. Uprights:60*80*1.8/2.0mm; 70*90/100*1.8*2.0mm; 80*120*2.0mm steel;

5. Box-beam:80/100/120/140/160*50*1.5mm

6. Connect bar: 200-300mm

7. Surface treatment:powder coating treatment.

Main Parts Specs:

1. Upright section: 80*60*2.0, 90*70*2.0, 100*70*2.0, etc.
2. Boxed beams section: 80*50*1.5, 100*50*1.5, 120*50*1.5, 140*50*1.5, 160*50*1.5, etc.

Step beams section: 80*50*1.5, 100*50*1.5, 120*50*1.5, etc.

3. Horizontal & diagonal braces, upright footplates, safety pins, row spacers, post protectors, crash barriers, bolts & nuts, expansion anchors, pallet support, wire decks and other necessary components.
