| Chemical media | Max. Temperature Resistance (Degree Celsius) | |||
| Concentration % | Vinyl | m-Benzene | o-Phenylene | |
| Hydrochloric acid | 30 | 82 | 65 | Not recommended |
| Nitric acid | 35 | 38 | Not recommended | Not recommended |
| Sulfuric acid | 25 | 82 | 65 | Not recommended |
| Hydrofluoric acid | 10 | 24 | Not recommended | Not recommended |
| Lactic acid | 100 | 82 | 65 | 60 |
| Hypochlorite | Saturated | 60 | Not recommended | Not recommended |
| Trisodium phosphate | 50 | 82 | Not recommended | Not recommended |
| Citric acid | All | 49 | Not recommended | Not recommended |
| Potassium hydroxide | 10 | 49 | Not recommended | Not recommended |
| Sodium hydroxide | 10 | 82 | Not recommended | Not recommended |
| Calcium hydroxide | 25 | 82 | 65 | Not recommended |
| Calcium hypochlorite | 25 | 82 | 65 | Not recommended |
| Ferric chloride | 100 | 82 | 65 | 60 |
| Aluminum chloride | All | 82 | 65 | 60 |
| Mercury chloride | 100 | 82 | 65 | 60 |
| Silver nitrate | 100 | 82 | 65 | 60 |
| Fuel | All | 38 | 38 | 38 |
| Ammonium salts | All | 24 | Not recommended | Not recommended |
| Copper oxide | Glycerin | 52 | 52 | Not recommended |
| Sodium salt | All | 24 | Not recommended | Not recommended |
| Zinc chloride | All | 24 | 24 | Not recommended |
| Acetone | 100 | 124 | Not recommended | Not recommended |
| chloroform | 100 | Not recommended | Not recommended | Not recommended |
| Copper salt | All | 82 | 65 | 60 |
| Phenols | 10 | 24 | Not recommended | Not recommended |
| Ozone for water treatment | All | 38 | 38 | 38 |
| Bleaching solution (for paper mills) | All | 82 | Not recommended | Not recommended |
| Ammonia hydroxide | 30 | 24 | Not recommended | Not recommended |
| Paper mill black liquor | All | 82 | Not recommended | Not recommended |
| All | 100 | 82 | 65 | 60 |
| Sulfur Dioxide | Saturated | 82 | 65 | 60 |
| Water | 100 | 82 | 65 | 60 |
| Alum | All | 82 | 65 | 60 |
| Chlorine water | Saturated | 49 | Not recommended | Not recommended |
| Bonding | Tape connection or glue connection |
| Connection method | Bolting |
| Riveting | |
| Fasteners |
