I. Scope of application
The excitation principle and structure form of DZSF composite high frequency vibrating screen are different from the vibrating screen usually used, which has the advantages of light weight, low energy consumption, low lower limit of recycling (classification), small dynamic load, not easy to block the holes, and so on, and it is suitable for the classification, dewatering, desliming operation of fine-grained materials in coal, mine, building materials, abrasive, chemical industry, metallurgy, foodstuffs, medicine and so on.
Second, technical characteristics
2.1 equipment technical characteristics:
equipment model ——————————–DZSF1536
equipment external dimensions —————————-4092×2102×2673
equipment weight —————— ————–4000kg
Vibration amplitude——————————–0~3mm
Sieve surface inclination——————————–30/-5 degrees
Sieve hole size————————- ——-0.1~3 (optional)
2.2 Power distribution requirements:
Control cabinet input power supply ——-3660 V; 50Hz
Power ————————————4.2kW/per machine
